Cooling System Specifications For Your 1997-2001 Honda CR250 Dirt Bike
If you need parts and tools, make sure to buy them here!
Cooling System Specifications | |
| Coolant Type | Ethylene Glycol With Silicate-Free Corrosion Inhibitors For Aluminium Engines |
| Coolant Mixture | 50/50 Antifreeze 7 distilled Water |
| Cooling System Capacity | |
| 1997 – 1999 | |
| – At Change | 1.32 Quarts (1.26 liters) |
| – At Disassembly | 1.32 Quarts (1.26 liters) |
| 2000-2001 | |
| – At Change | 1.29 Quarts (1.22 liters) |
| – At Disassembly | 1.43 Quarts (1.35 liters) |
| Radiator Cap Release Pressure | 16-20 PSI |
Torque Specifications | N•n | in.-lb. | ft.-lb. |
| Coolant Drain Bolt | 10 | 88 | – |
| Water Pump Cover Bolts | 12 | 106 – I do not recomend this much torque. I have had several cover bolts break. | – |
| Water Pump Impeller | 12 | 106 | – |
